TECHNICAL SPECIFICATIONS

CAPACITY : : 450mm dia holes upto 50 mtrs by DTH method in steps.

MOUNTING : Skid – Carry on Truck

TOP HEAD

Driving System : Hydraulic Motor & Gear Box

Max. Torque  450 kg.mtr

Max. RPM : 0 to 80 RPM

FEED SYSTEM

Driving System : Hydraulic Cylinder with Chain Combination

Max. Thrust force : 19000 kgs

HYDRAULIC LEVELLING JACKS

Number of Cylinders : 4 Nos.

Max. Capacity of each Cylinder  19635 kgs.

Cylinder Specification  125 dia x 70 dia x NCLM610

WELDING GENERATOR

Capacity of Welding Gen. Set  400 Amps

WATER PUMP

Capacity  50 LPM @ 400 PSI

HYDRAULIC OIL COOLER

Heat dissipation capacity  50,000 K.cal / hr

Max. Flow  400 LPM

DECK ENGINE

Make  Cummins/Equivalent

Capacity  260 HP @ 2600 RPM

SKID MOUNTED HORIZONTAL DRILLING RIG (DTH-HD-450-150)

Technical Specifications
Type
Piston stroke
Cyd. Dia.
Discharge Cap.
Discharge Pre.
Discharge Bore
Suction Bore
Power system
Weight
Length
Width
Height without Lever

HAND GROUT PUMP

Horizontal Single Cylinder
35 mm
120 mm
8 L/Min
10 kg/cm2
19 mm
25 mm
Hand Feed
28 kg.
770 mm
235 mm
565 mm

Drilling Capacity

 ROTATION HEAD:

 Max. Output TorqueFEED:

 Max. pull up force

 Max. Pull down force

 Max. Pull up speed

1 TON AUXILIARY WINCH:

 Max. Lifting Capacity

 Max.pull down force

MAST RAISING CYLINDER:

Number of Cylinders

Max. Capacity of cylinder : 11782 kg. @ 160 bar

Cylinder Specification : 100 Dia x 50 Dia x NCCM 800

HYDRAULIC LEVELLING JACKS:

Number of Cylinders : 4 Nos.

Max. Capacity of each Cylinder : 11782 kg. @ 160 bar

Cylinder Specification : 100 Dia x 63 Dia x NCLM 610

BREAKOUT CYLINDER:

Max. Pull back Force : 9428 kg.

WATER PUMP:

Capacity : 36 LPM  @ 400 PSI ( 28 bar)

HYDRAULIC OIL COOLER:

Heat dissipation capacity : 40,000 K.cal / hr

Max. Flow  200 LPM

RAIL MOUNTED ANGLE DRILLING MACHINE

115/152 mm dia holes upto a depth of 45 mtrs by DTH and Odex method

200 kg. mtr. @ 60 RPM

5500 kg.
4500 kgs
15 mtr / min.

1000 kg
10 mt / min

1 No.

Capacity
Rig CarrierROTATION HEADMax. Output Torque
Max. Speed
H.P of Motor
Air Motor
Gear BoxFEED
Max. Pull up force
Max. Pull down force
Max. Pull up speed
H.P of Motor
Air Motor
Gear Box

MAST RAISING CYLINDER
Number of Cylinder
Operating System

MECHANICAL LEVELLING JACKS

OPTIONAL:
MAST DUMPING
Number of Cylinder
Mast Swiveling

Water Pump

5” Dia DTH Holes upto 60 mts in Hard formation
Skid Mounted Rig for under ground mines150Kg.mt
60 rpm
8 HP
4 cylinder Radial Piston Air Motor
Spur Reduction Gear Box1500 kg
1500 kg
10 mt/min
10 HP
4 cylinder Radial Piston Air Motor
Self locking worm & worm wheel reduction gear box,
Chain & tyre

1 No
Pneumatically operated hydraulic pump,
Directional control valve and hydraulic cylinder

4 Nos.

Hydraulically operated dumping arrangement for angle hole drilling upto 20 degrees.
1 No
Manually operated swiveling of 5 degrees on eighter sides of vertical
Hydraulically operated water pump
36 LPM @ 400 psi.

SKID MOUNTED RIG FOR UNDERGROUND MINES

It can be carried easily from place to place manually because of lesser weight

Drilling Capacity

TOP HEAD
Driving System
RPM
Max. Torque

FEED SYSTEM
Driving System
Max. Pull down force
Max. Pull up force

TRACK DETAILS
Track shoe width
Track length
Track width
Max. Speed
Gradability

DECK ENGINE
Make
Capacity

AUXILIARY HOIST:
Capacity

MAIN HOIST:
Capacity

HYDRAULIC LEVELLING JACKS
Number of Cylinders
Max. Capacity of each cylinder
Cylinder specification

MUD PUMP
Make
Model
Capacity

CRAWLER MOUNTED PILE DRILLING RIG

254 to 610mm dia holes upto 30 ft.

Hydraulic Motor & Gear Box.
0 – 60 RPM
500 kg.mtr @ 30 RPM

Hydraulic Cylinder & Multiplier
2200 kgs
3800 kgs

260mm
3300mm
2000mm
1.6 km/hr
30 deg.

Ashok Leyland/Equivalent
128 HP @ 2400 RPM

1000 kgs driven by Hydraulic Motorangle hole drilling

4000 kgs driven by Hydraulic Motor.

4 Nos.
11782 kgs
100 dia x 60 dia x NCLM610

Kirloskar
Centrifugal
2000 ltrs/min

TECHNICAL SPECIFICATIONS

CAPACITY : : 800mm dia pile by Auger Drilling.

MOUNTING : Heavy Duty Crawler

ROTATION: : Bent Axis Hydraualic Motors & Spur Gear Box

Torque : 4000 kg.mtr.

Speed : 10 to 90 RPM

Feed

Pull up : 30 Tons

Pull down : 14.7 Tons

Main Hoist : 12 Tons

Auxiliary Hoist : 6 Tons

Power Pack : Hydraulic Pumps

Max Drilling depth : 25 mtrs

SECO BEC-TRACK-800-25
